Author Topic: Cabin wiring loom routing  (Read 3083 times)

Minerva

  • Full Member
  • Regular
  • **
  • Ireland, Connaught, Manorhamilton
  • Posts: 98
Cabin wiring loom routing
« on: January 03, 2019, 15:04:57 »
Hi all.
I'm just putting back together a 230sl and wondering what route the rear loom takes from the rear bulkhead forwards. It is clipped the the floorpan or is it left loose? Any pictures would be great.
Thanks
Keith.
Logged

specracer

  • Full Member
  • Senior
  • ***
  • USA, MA, Duxbury
  • Posts: 245
Re: Cabin wiring loom routing
« Reply #1 on: January 05, 2019, 13:13:33 »
It runs down under the A pillar on drivers side, and down the door sill up against the vertical seam. It is covered by the silver scuff door sill trim.
Logged

EeVeeWee

  • Full Member
  • Silver
  • ****
  • Netherlands, Utrecht, Leusden
  • Posts: 387
Re: Cabin wiring loom routing
« Reply #2 on: January 05, 2019, 14:31:51 »
Here you can see it at the left side of the picture.

Logged
Again something else.

EeVeeWee

  • Full Member
  • Silver
  • ****
  • Netherlands, Utrecht, Leusden
  • Posts: 387
Re: Cabin wiring loom routing
« Reply #3 on: January 05, 2019, 14:38:42 »
And here underneath the door sill trim:

Logged
Again something else.

Minerva

  • Full Member
  • Regular
  • **
  • Ireland, Connaught, Manorhamilton
  • Posts: 98
Re: Cabin wiring loom routing
« Reply #4 on: January 05, 2019, 22:51:45 »
That's absolutely great! Thanks to both of you, the old loom had been burnt previously  so had no idea if it went there or through the seat crossmember.
Thanks again
Keith.
Logged

114015

  • Full Member
  • Platinum
  • ******
  • Germany, Nordrhein-Westfalen, Tecklenburg
  • Posts: 2080
Re: Cabin wiring loom routing
« Reply #5 on: January 11, 2019, 23:32:52 »


Ireland.

Hello Keith,
Is your car LHD or RHD ?


Achim


Logged
Achim
(Germany)

Minerva

  • Full Member
  • Regular
  • **
  • Ireland, Connaught, Manorhamilton
  • Posts: 98
Re: Cabin wiring loom routing
« Reply #6 on: January 13, 2019, 14:47:38 »
Hi Achim it's a lid 230.
Keith.
Logged

114015

  • Full Member
  • Platinum
  • ******
  • Germany, Nordrhein-Westfalen, Tecklenburg
  • Posts: 2080
Re: Cabin wiring loom routing
« Reply #7 on: January 16, 2019, 12:39:39 »

Dear Keith,
Ah, a left-hand-drive, right?
Thanks a lot, that's the piece of info I need.
Because I can help you with that ... but not with the routing of a RHD Pagoda.

Please see my next response

https://www.sl113.org/forums/index.php?topic=28631.msg206803#msg206803


Best,

Achim
Logged
Achim
(Germany)

Minerva

  • Full Member
  • Regular
  • **
  • Ireland, Connaught, Manorhamilton
  • Posts: 98
Re: Cabin wiring loom routing
« Reply #8 on: January 19, 2019, 17:15:39 »
Thanks Achim, I'll put it in loosely and post a photo to see if you agree.
Keith
Logged
